Patient Lift Y401 by INTCO Medical - Enhance Mobility
Y401
- Frame: Steel, powder coating
- Chassis Length: 1070mm
- Chassis Width: 600mm-800mm
- Lifting Height: 830mm-1850mm
- Handle Height: 1000mm
- Caster Height: 90mm
- Motor: DC 24V 8000N
- Battery: DC 24V 5Ah, rechargeable battery Approx. 60 lifts per full charge
- Charger: 24V-1A
- Charging Time: 6 hours per time
- Front Caster: 3"solid tire, plastic wheel optional
- Rear Caster: 4"solid tire with locking, plastic wheel optional
- Max. User Weight: 150 kg (23.62 stone)
- Alternatives: Purpose designed sling
- Package: 1260*630*350mm
- G./N.W.: 51/43 kg
Product Parameters
| Chassis Length(mm) | Chassis Width(mm) | Lifting Height(mm) | Handle Height(mm) | Caster Height(mm) | Motor | Charger | Front Caster Spec. | Rear Caster Spec. | Max. User Weight(kg) | G./N. Weight(kg) | Carton Size(mm) |
| 1070 | 600-800 | 830-1850 | 1000 | 90 | DC 24V 8000N | 24V-1A | 3" | 4" | 150 | 51/43 | 1260*630*350 |
