lift-3

LIFT

Home Products Lift

Y401

Frame: Steel, powder coating
Chassis Length: 1070mm
Chassis Width: 600mm-800mm
Lifting Height: 830mm-1850mm
Handle Height: 1000mm
Caster Height: 90mm
Motor: DC 24V 8000N
Battery: DC 24V 5Ah, rechargeable battery Approx. 60 lifts per full charge
Charger: 24V-1A
Charging Time: 6 hours per time
Front Caster: 3"solid tire, plastic wheel optional
Rear Caster: 4"solid tire with locking, plastic wheel optional
Max. User Weight: 150 KGS (23.62 stone)
Alternatives: Purpose designed sling
Package: 1240*630*350mm
G./N.W. 51/43 KGS

Product parameters

Chassis Length(mm) Chassis Width(mm) Lifting Height(mm) Handle Height(mm) Caster Height(mm) Motor Charger Front Caster Spec. Rear Caster Spec. Max. User Weight(kg) G./N. Weight(kg) Carton Size(mm)
1070 600-800 830-1850 1000 90 DC 24V 8000N 24V-1A 3″ 4″ 150 51/43 1240*630*350
